DIMENSION

L×W×H  (mm)

1780×640×1120

Wheel Base (mm)

1250

Ground Clearance(mm)

110

Seat Light  (mm)

750

N.W  ( LBS)

190

G.W. (LBS)

200

ENGINE

Serial

1P39QMB 4STROKE

Bore×Stroke   (mm)

39×41.5

Displacement  (ml)

49.6

Compress Rate

10.4:1

Max Power  (kW/r/min)

2.4/7000±500

Rated Power  (kW/r/min)

2.1/6500±500

Max Torque  (N·m/r/min)

3.6/6000±500

Idle Speed  (r/min)

1700±100

Fuel Consumption  (g/kW·h)

400

Start

Electric / Kick

Ignition

C.D.I

Transmission

V-Belt

Fuel System

Carb.

Shengwey PD19J

Fuel Tank  (L)

4.90

Driven System

Rim(F/R)

2.15×12  /  2.15×12 Alloy Rim

Tire(F/R)

120/70-12   /  120/70-12  Huajian

Brake System

Brake Type

F

Hydraulic Disc

R

Drum

Operation Type

F

Hand Operation

R

Hand Operation

Electric System

Spark Plug Type / Gap(mm)

A7RTC  /  0.6?0.7

Battery Type

12V 5Ah

Head Light

Double Light(LED)

Main Performance

Max Speed (km/h)

52

Start Time(s)

15

Rconomic Fuel Consumption(L/100km)

2.0

Packing

Packing  Type

Carton with steel frame inside.Disassemble front rim, front cover/handle bar

Packing Size (mm)

1685×565×830

Load Capacity

84pcs/ 40HQ

G.W.(LBS)

220
