SPECIFICATIONS
|
CONFIGURE :
|
Decals (Y/N) :
|
Y
|
Sundries box(Y/N) :
|
Y (accessory)
|
Remote start (Y/N) :
|
Y
|
Remote engine stop (Y/N)
|
Y
|
Speed limiter (Y/N) :
|
Y
|
Assembly required :
|
Rearview mirror,battery,Sundries box,handle bar,front wheel,front fender,
front cover and headlight,rear carrier
|
ENGINE INFO :
|
Engine type :
|
4-stroke,single cylinder
|
Engine brand :
|
|
Displacement :
|
150cc
|
Cooling :
|
Air-cooled
|
Max horsepowe :
|
2.7hp/7500rpm
|
Max torque :
|
3.0n.m/4500rpm
|
Bore*stroke :
|
1.54*1.63 inch
|
Max speed :
|
28mile/h
|
Climbing ability :
|
15degree
|
Ignition :
|
C.D.I
|
Starting system :
|
Electric/kick
|
Battery :
|
12V/7Ah
|
Carburetor brand :
|
PD19J
|
Engine oil :
|
SAE15W/40 SF
|
Gear oil :
|
80W/90
|
CHASSIS ETC :
|
Clutch :
|
Automatic
|
Transmission :
|
1-speed
|
Driveline :
|
CVT
|
Driving wheel :
|
Rear wheel drive
|
Suspension,front/rear :
|
Hydraulic damper/single spring
|
Brakes,front/rear :
|
Disc/drum
|
Brake operation :
|
Hand
|
Tires,front/rear :
|
130/60-13 / 120/70-17
|
Fuel capacity/type :
|
1.6gal
|
Weight,G.W./N.W :
|
286 /242lbs
|
Max load :
|
165.3 lbs
|
DIMENSIONS :
|
Wheelbase :
|
54.1inch
|
Overall L*W*H :
|
78*28*44.5inch
|
Height to seat :
|
28.7inch
|
Min ground clearance :
|
4.7inch
|
Carton size :
|
74.8*22.4*33.9inch
|
|
|
|
|
