SPECIFICATIONS
|
CONFIGURE :
|
Decals (Y/N) :
|
Y
|
Sundries box(Y/N) :
|
Y (accessory)
|
Remote start (Y/N) :
|
Y
|
Remote engine stop (Y/N)
|
Y
|
Remote alarm (Y/N) :
|
Y
|
Speed limiter (Y/N) :
|
Y
|
Assembly required :
|
Rearview mirror, battery, Sundries box, handle bar, front wheel, front fender,
front cover and headlight, rear carrier
|
ENGINE INFO :
|
Engine type :
|
4 stroke, single cylinder
|
Displacement
|
150 cc
|
Cooling
|
Air cooled
|
Max horsepower
|
2.7hp / 7500rpm
|
Max torque
|
3.0n.m / 4500rpm
|
Bore Stroke
|
1.54 1.63 inch
|
Max speed
|
28 MPH
|
Climbing ability :
|
15degree
|
Ignition :
|
C.D.I
|
Starting system :
|
Electric / kick
|
Battery :
|
12V / 7Ah
|
Carburetor brand :
|
PD19J
|
Engine oil :
|
SAE15W / 40 SF
|
Gear oil :
|
80W / 90
|
CHASSIS ETC :
|
Clutch :
|
Automatic
|
Transmission :
|
1 speed
|
Driveline :
|
CVT
|
Driving wheel :
|
Rear wheel drive
|
Suspension,front/rear :
|
Hydraulic damper / single spring
|
Brakes,front/rear :
|
Disc / drum
|
Brake operation :
|
Hand
|
Tires,front/rear :
|
130 / 60-13 / 120 / 70-17
|
Fuel capacity/type :
|
1.6 gal
|
Weight,G.W./N.W :
|
286 / 242lbs
|
Max load :
|
165.3 lbs
|
| DIMENSIONS : |
Wheelbase :
|
54.1inch
|
OA L * W * H :
|
78 * 28 * 44.5inch
|
Height to seat :
|
28.7 inch
|
Min ground clearance :
|
4.7 inch
|
|
|
|
|
