SPECIFICATIONS
|
ENGINE
|
Engine Type:
|
1P52FMI,Single cylinder,4-stroke,air cooling
|
Disceplement(ml):
|
119.6
|
Bore X Stroke (mm):
|
52.4x55.5
|
Compression Ratio:
|
9.0:1
|
Max. Power (kw/r/min):
|
5.7/7000
|
Max. Torque (N.m/r/min):
|
8.0/5500
|
Max. Speed (km/h)
|
50
|
Lubrication:
|
Pressed/Splash
|
Clutch Type:
|
Manual
|
Ignition:
|
C.D.I
|
| Starting System: |
Electric/ kick start
|
| Transmision System |
Chain drive
|
CHASSIS
|
Front Suspension
|
Telescopic shock absorber
|
Rear Suspension
|
Mono shock absorber
|
Front Brake
|
Hydraulic disk
|
Rear Brake
|
Hydraulic disk |
Front Tire
|
2.50-14
|
Rear Tire
|
2.75-12
|
Battery
|
12V9AH
|
DIMENSIONS
|
LXWXH (mm)
|
1410x795x940
|
Seat Height (mm)
|
730
|
Wheelbase (mm)
|
1000
|
Min. Ground Clearance (mm)
|
280
|
Max. Permissionable Weight (kg)
|
75
|
Dry. Weight (kg)
|
52
|
Fule Tank Capacity (L)
|
3.4
|
OTHERS
|
Packing Size (mm)
|
1390x380x660
|
Packing Weight (kg)
|
78
|
Container Loading:
|
72units/20', 196 units/40' HQ
|
EEC/EPA/CARB:
|
EPA/CARB
|
|
|
|
|
Budget Plan - Package Deal
|
|
 |
4 units purchase
|
|
|




|
