Wholesale 125cc ATV
Japanese Racing Type R12 UPGRADED MODEL


Tel. USA : 718-766-5432
Fax. USA: 718-766-5426

U.S.A.  Business Hours (EST.)
Mon. - Fri.:    9a.m. -  6 p.m.
Sat. - Sun.:          Closed

Become a powersports dealer now DEALERS
 WANTED

wholesale distributor - online application






125cc racing  ATV
minimum order for this unit

Wholesale ATV

MFB-R12

Gas Quad ATV

Displacement 125cc

Starting from :
$000.00

Racing ATV Top Quality


 Semi-automatic with reverse

Back to ATV    110cc   125cc   150cc   200cc  250cc  350cc+
Call to order : 718-766-5432
SPECIFICATIONS
overall length
2225mm
overall width
1180mm
overall height
875mm
seat height
635mm
max.non-limited speed
(65±5)Km/h
ground clearance
80mm
wheelbase 1410mm
climbing angle
20 degrees
max.steering angle
30 degrees
wheels air pressure
22Psi
unladen mass 137Kg
complete vehicle kerb mass
141Kg
passenger no.
1
transmission type
chain
brake front/rear:disc brake by hand/foot
trire size
235/30-12
fuel tank
4.1L
gasoline type RQ90# or higher
battery type
12V6.5Ah
lamps
two front big lamps,one rear tail lamp
engine type
152FMH,4-stroke,single cylinder
number of cylinders
1
cooling system
air cool
spark plug valve
0.6-0.7mm
starting type
electric
ignition type
C.D.I
carburetor type
PZ20
lubrication type
press/splash
clutch type
auto wet-multi
lowest fuel comsumption
367g/kw.h
lubricant type
SF15W/40 or similar
idle speed 1500±150 r/min
bore x stroke
54×54mm
displacement
123.6ml
compression rate
9.3:1
max.power
6.1/7500(1±5%)KW/rpm
max.torque
8.0/6000((1±5%)N.m/rpm
wholesale 125cc racing quad atv
wholesale 125cc racing quad atv
wholesale 125cc racing quad atv
wholesale 125cc racing quad atv
